Standard carrying handle 190mm SAV
Home
/
Catalog
/
Handles / Slinging / Liftings slings / Back Plates
/
Standard Carrying Handles
/ Standard carrying handle 190mm SAV
Description
Technical sheet
Stamped plate, thickness 1.5mm, milling impression 3 holes Ø 5 mm.
2 crimped ring supports.
Steel wire ring.
The plate and the ring are integral.
Light duty handle (40kg in use, 90kg before deformation)
Multi-purpose use.
90° ring lock.
Possible to mount on top of packaging.
Download IGS file
MATERIAL
FINISH
A
B
C
D
E
F
G
THEORETICAL
WEIGHT
kg/hundred
REFERENCES
Steel
raw
190
107
82
27
7
14,5
48
12,500
PO.310-BBR
Steel
yellow zinc
190
107
82
27
7
14,5
48
12,500
PO.310-BZB*
Steel
White zinc
190
107
82
27
7
14,5
48
12,500
PO.310-BZI
Stainless steel 18/8
Raw
190
107
82
27
7
14,5
48
12,500
PO.310-BIB
* Articles made on request
